Product Summary

The STM32F407ZGT6 is a MCU. It is based on the high-performance ARMCortex-M4 32-bit RISC core operating at a frequency of up to 168 MHz. The STM32F407ZGT6 features a Floating point unit (FPU) single precision which supports all ARM single-precision data-processing instructions and data types. The STM32F407ZGT6 also implements a full set of DSP instructions and a memory protection unit (MPU) which enhances application security. The Cortex-M4 core with FPU will be referred to as Cortex-M4F throughout this document.

Parametrics

STM32F407ZGT6 absolute maximum ratings: (1)External main supply voltage:–0.3 to 4.0V; (2)Input voltage on five-volt tolerant pin:VSS–0.3 to VDD+4V; (3)Input voltage on any other pin VSS:–0.3 to 4.0V; (4)Variations between different VDD power pins: 50mV; (5)Variations between all the different ground pins: 50mV.

Features

STM32F407ZGT6 features: (1)1.8 V to 3.6 V application supply and I/Os ; (2)POR, PDR, PVD and BOR ; (3)4-to-26 MHz crystal oscillator ; (4)Internal 16 MHz factory-trimmed RC (1% accuracy) ; (5)32 kHz oscillator for RTC with calibration ; (6)Internal 32 kHz RC with calibration ; (7)Sleep, Stop and Standby modes ; (8)VBATsupply for RTC, 20×32 bit backup registers + optional 4 KB backup SRAM.

Diagrams

STM32F407ZGT6 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
STM32F407ZGT6
STM32F407ZGT6

STMicroelectronics

ARM Microcontrollers (MCU) ARM M4 1024 FLASH 168 Mhz 192kB SRAM

Data Sheet

0-1: $8.85
1-10: $8.04
10-100: $6.83
100-250: $6.23
