Product Summary
The L7805CDT is a three-terminal positive regulator. It is available in TO-220, TO-220FP, TO-220FM, TO-3 and D2PAK packages and several fixed output voltages, making it useful in a wide range of applications. The L7805CDT can provide local on-card regulation, eliminating the distribution problems associated with single point regulation.
Parametrics
L7805CDT absolute maximum ratings: (1)DC Input Voltage:35 or 40V; (2)Output Current:Internally Limited; (3)Power Dissipation:Internally Limited; (4)Storage Temperature Range:-65 to 150℃; (5)Operating Junction Temperature Range:0 to 150℃.
Features
L7805CDT features: (1)output current to 1.5A; (2)output voltages of 5; 5.2; 6; 8; 8.5; 9; 10; 12; 15; 18; 24V; (3)thermal overload protection; (4)short circuit protection; (5)output transition soa protection.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
L7805CDT |
STMicroelectronics |
Linear Regulators - Standard 5.0V 1.0A Positive |
Data Sheet |
Negotiable |
|
|||||||||||||
L7805CDT-TR |
STMicroelectronics |
Linear Regulators - Standard 5.0V 1.0A Positive |
Data Sheet |
|
|
