L78L05ABUTR

three-terminal positive regulator, Output current up to 100 mA, 5V, TO-92, Short circuit protection

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.01~0.02 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.01~0.02

PartNumber:: L78L05ABUTR

Brand:: STMicroelectronics - ST | Pack: SOT | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Candy Wang's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-31

From Other Seller

Part Number:L78L05ABUTR
US $0.01 - 0.02
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The L78L05ABUTR of three-terminal positive regulator employ internal current limiting and thermal shutdown, making them essentially indestructible. If adequate heat-sink is provided, they can deliver up to 100 mA output current.c The L78L05ABUTR is intended as fixed voltage regulator in a wide range of applications including local or oncard regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, the L78L05ABUTR can be used with power pass elements to make high-current voltage regulators. The L78L05ABUTR used as Zener diode/resistor combination replacement, offers an effective output impedance improvement

Parametrics

L78L05ABUTR absolute maximum ratings: (1)Output voltage, TJ = 25 ℃, VO: 3.036 to 3.564V; (2)Output voltage, IO = 1 to 40mA, VI=5.3 to 20V, VO: 2.97 to 3.63V; (3)Output voltage, IO = 1 to 70mA, VI=8.3V, VO: 2.97 to 3.63V; (4)Line regulation, VI = 5.3 to 20V, TJ = 25℃, ΔVO: 150mV; (5)Line regulation, VI = 6.3 to 20V, TJ = 25℃, ΔVO: 100mV; (6)Load regulation, IO = 1 to 100 mA, TJ = 25℃, ΔVO: 60mV; (7)Load regulation, IO = 1 to 40 mA, TJ = 25℃, ΔVO: 30mV; (8)Quiescent current, TJ = 25℃, Id: 6mA; (9)Quiescent current, TJ = 125℃, Id: 5.5mA; (10)Quiescent current change, IO=1 to 40mA, ΔId: 0.2mA; (11)Quiescent current change, VI=6.3 to 20V, ΔId: 1.5mA.

Features

L78L05ABUTR features: (1)Output current up to 100 mA; (2)Output voltages of 5V; (3)Thermal overload protection; (4)Short circuit protection; (5)No external components are required; (6)Available in either ± 4 % (AC) or ± 8 % (C)selection.
