Product Summary

The VND600SPTR-E is a monolithic device made using STMicroelectronics VIPower M0-3 technology. It is intended for driving resistive or inductive loads with one side connected to ground. The VND600SPTR-E has two channels in high-side configuration; each channel has an analog sense output on which the sensing current is proportional (according to a known ratio) to the corresponding load current.

Parametrics

VND600SPTR-E absolute maximum ratings: (1)DC supply voltage: 41 V; (2)Reverse supply voltage: -0.3 V; (3)DC reverse ground pin current: -200 mA; (4)Output current: Internally limited; (5)Reverse output current: -21 A; (6)Input current: ±10 mA; (7)Current sense maximum voltage:-3V to +15V.

Features

VND600SPTR-E features: (1)Automotive Grade: compliance with AEC Guidelines; (2)Very low standby current; (3)CMOS compatible input; (4)Proportional load current sense; (5)Current sense disable; (6)Thermal shutdown protection and diagnosis; (7)Undervoltage shutdown; (8)Overvoltage clamp; (9)Load current limitation.

Diagrams

VND600SPTR-E block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
VND600SPTR-E
VND600SPTR-E

STMicroelectronics

Power Switch ICs - Power Distribution 36V 25A Hi-Side SSR

Data Sheet

0-325: $2.42
325-500: $2.18
500-600: $2.18
600-1000: $1.84
