Product Summary
The SMJ320F2812HFGM150 is a Digital Signal Processor for demanding control applications.
Parametrics
SMJ320F2812HFGM150 absolute maximum ratings: (1)Supply voltage range, VDDIO, VDDA1, VDDA2, VDDAIO, and AVDDREFBG : -0.3 V to 4.6 V; (2)Supply voltage range, VDD, VDD1: -0.5 V to 2.5 V; (3)VDD3VFL range: -0.3 V to 4.6 V; (4)Input voltage range, VIN: -0.3 V to 4.6 V; (5)Output voltage range, VO: -0.3 V to 4.6 V; (6)Input clamp current, IIK (VIN < 0 or VIN > VDDIO): ± 20 mA; (7)Output clamp current, IOK (VO < 0 or VO > VDDIO): ± 20 mA; (8)Operating ambient temperature range, TA: -55 to 125℃; (9)Storage temperature range, Tstg: -65 to 150℃.
Features
SMJ320F2812HFGM150 features: (1)High-Performance Static CMOS Technology; (2)JTAG Boundary Scan Support; (3)High-Performance 32-Bit CPU; (4)On-Chip Memory; (5)Boot ROM; (6)External Interface; (7)Clock and System Control; (8)Three External Interrupts; (9)Peripheral Interrupt Expansion (PIE) Block That Supports 45 Peripheral Interrupts; (10)128-Bit Security Key/Lock.
Diagrams
 |
