Product Summary

The IRF1010EZPBF is an automotive mosfe. Specifically designed for Automotive applications, the IRF1010EZPBF utilizes the latest processing techniques to achieve extremely low on-resistance per silicon area. These features combine to make this design an extremely efficient and reliable device for use in Automotive applications and a wide variety of other applications.

Parametrics

IRF1010EZPBF absolute maximum ratings: (1)Continuous Drain Current, VGS @ 10V (Silicon Limited):84A; (2)Continuous Drain Current, VGS @ 10V (See Fig. 9):60A; (3)Continuous Drain Current, VGS @ 10V (Package Limited):75A; (4)Pulsed Drain Current:340A; (5)Linear Derating Factor:0.90W/℃; (6)Gate-to-Source Voltage:±20V; (7)Single Pulse Avalanche Energy (Thermally Limited):99mJ; (8)Single Pulse Avalanche Energy Tested Value:180mJ; (9)Operating Junction and Storage Temperature Range:-55 to 175℃.

Features

IRF1010EZPBF features: (1)Advanced Process Technology; (2)Ultra Low On-Resistance; (3)Dynamic dv/dt Rating; (4)175℃ Operating Temperature; (5)Fast Switching; (6)Repetitive Avalanche Allowed up to Tjmax; (7)Lead-Free.

Diagrams

IRF1010EZPBF circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IRF1010EZPBF
IRF1010EZPBF

International Rectifier

MOSFET MOSFT 60V 84A 8.5mOhm 58nC

Data Sheet

0-1: $0.84
1-25: $0.75
25-100: $0.72
100-250: $0.68
