Product Summary

The TIP127 is a silicon Epitaxial-Base NPN power transistor in monolithic Darlington configuration mounted in Jedec TO-220 plastic package. They are intented for use in power linear and switching applications. The complementary PNP type is TIP122, respectively.

Parametrics

TIP127 absolute maximum ratings: (1)Collector-Base Voltage (IE = 0), VCBO: 100 V; (2)Collector-Emitter Voltage (IB = 0), VCEO:100 V; (3)Emitter-Base Voltage (IC = 0), VEBO: 5 V; (4)Collector Current, IC: 5 A; (5)Collector Peak Current, ICM: 8 A; (6)Base Current, IB: 0.1 A; (7)Total Dissipation at Tcase ≤ 25℃, Ptot: 65W; Tamb ≤ 25℃, Ptot: 2W; (8)Storage Temperature, Tstg: -65 to 150℃; (9)Max. Operating Junction Temperature, Tj: 150℃.

Features

TIP127 feature: STMicroelectronics preferred salestypes.

Diagrams

TIP127 circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TIP127/MOR
TIP127/MOR

Other


Data Sheet

Negotiable
TIP127F
TIP127F

Other


Data Sheet

Negotiable
TIP127FP
TIP127FP

STMicroelectronics

Transistors Darlington PNP Power Darlington Vceo/Vcbo 100 IC 5

Data Sheet

0-1: $0.31
1-10: $0.29
10-100: $0.28
100-250: $0.26
TIP127G
TIP127G

ON Semiconductor

Transistors Darlington 5A 100V Bipolar Power PNP

Data Sheet

0-1: $0.43
1-25: $0.38
25-100: $0.29
100-500: $0.25
TIP127-S
TIP127-S

Bourns

Transistors Darlington PNP DARLINGTON 100V 5A

Data Sheet

Negotiable
TIP127TU
TIP127TU

Fairchild Semiconductor

Transistors Darlington PNP Epitaxial Darl

Data Sheet

0-1: $0.39
1-25: $0.32
25-100: $0.23
100-250: $0.20
TIP127-BP
TIP127-BP

Micro Commercial Components (MCC)

Transistors Bipolar (BJT) PNP -100V -5A 40W

Data Sheet

0-1000: $0.40
TIP127
TIP127

STMicroelectronics

Transistors Darlington PNP Power Darlington

Data Sheet

0-1: $0.30
1-10: $0.28
10-100: $0.25
100-250: $0.22
