Product Summary

The SIM08 a high-performance host-based GPS module. It cooperates with SIM900 module in offering best-in-class acquisition and tracking sensitivity, Time-To-First-Fix, accuracy and ultra-low power consumption, allowing you to benefit from small dimensions and cost-effective solutions.

Parametrics

SIM08 general specifications: (1)Receiver type; (2)42-channel,; (3)GPS L1 C/A code,; (4)High-performance STE engine; (5)Max. update rate 2 Hz; (6)Sensitivity; (7)Tracking: -160 dBm; (8)Acquisition (Cold starts) : -146 dBm; (9)Time-To-First-Fix2; (10)Cold starts: < 35s; (11)Hot starts: <2s; (12)Accuracy2; (13)Horizontal position: <2.5m CEP; (14)Operation temperature: -40 to +85℃; (15)1 Demonstrated with a good active antenna; (16)2 All SV @ –130 dBm.

Features

SIM08 features: (1)Power supply: 3.0 V to 4.5V; (2)Power consumption; (3)Acquisition TBD (passive antenna); (4)Tracking TBD (passive antenna); (5)Antenna type Active and passive; (6)Antenna power External or internal VCC_ANT 2.8V.

Diagrams

SIM08 pin configuration
